Materials

Materials
Note: We recommend using DOT 4 Low
Viscosity (LV) High Performance Brake Fluid
or equivalent meeting WSS-M6C65-A2. Use
of any fluid other than the recommended
fluid could cause reduced brake
performance and not meet our performance
standards...
Other information:
Diagnostic Trouble Code (DTC) Chart
Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices. REFER to: Diagnostic Methods (100-00 General Information, Description and Operation).
Diagnostic Trouble Code Chart
Module
DTC
Description
Action
ABS
B1111:4B
Electric Park Brake Enable:Over Temperature
GO to Pinpoint Test F
ABS
B1111:53
Electric Park Brake Enable:Deactivated
GO to Pinpoint Test G
ABS
B1111:54
Electric Park Brake Enable:Missing Calibration
GO to Pinpoint Test E
ABS
C0609:01
Park Brake Switch Circuit:General Electrical Failure
GO to Pinpoint Test B
ABS
C0616:9A
Park Brake Control Module Control Circuit Performance:Component or System Operating Conditions
GO to Pinpoint Test B
ABS
C1034:01
Park Brake:General Electrical Failure
GO to Pinpoint Test B
ABS
C1034:07
Park Brake:Mechanical Failures
GO to Pinpoint Test K
ABS
C1034:13
Park Brake:Circuit Open
GO to Pinpoint Test B
ABS
C1034:25
Park Brake:Signal Shape/Waveform Failure
GO to Pinpoint Test B
ABS
C1034:2F
Park Brake:Signal Erratic
GO to Pinpoint Test B
ABS
C1034:47
Park Brake:Watchdog/Safety µC Failure
GO to Pinpoint Test B
ABS
C1034:48
Park Brake:Supervision Software Failure
GO to Pinpoint Test B
ABS
C1034:57
Park Brake:Invalid/Incompatible Software Component
GO to Pinpoint Test B
ABS
C1034:71
Park Brake:Actuator Stuck
GO to Pinpoint Test C
ABS
C1034:77
Park Brake:Commanded Position Not Reachable
GO to Pinpoint Test C
ABS
C1034:78
Park Brake:Alignment Or Adjustment Incorrect
GO to Pinpoint Test H
ABS
C1034:97
Park Brake:Component or System Operation Obstructed or Blocked
GO to Pinpoint Test D
ABS
C1A43:98
Motor Supply:Component or System Over Temperature
GO to Pinpoint Test D
ABS
C2005:18
Right Actuator:Circuit Current Below Threshold
GO to Pinpoint Test D
ABS
C2005:19
Right Actuator:Circuit Current Above Threshold
GO to Pinpoint Test D
ABS
C2005:77
Right Actuator:Commanded Position Not Reachable
GO to Pinpoint Test C
ABS
C2005:78
Right Actuator:Alignment Or Adjustment Incorrect
GO to Pinpoint Test A
ABS
C2006:18
Left Actuator:Circuit Current Below Threshold
GO to Pinpoint Test D
ABS
C2006:19
Left Actuator:Circuit Current Above Threshold
GO to Pinpoint Test D
ABS
C2006:77
Left Actuator:Commanded Position Not Reachable
GO to Pinpoint Test C
ABS
C2006:78
Left Actuator:Alignment Or Adjustment Incorrect
GO to Pinpoint Test A
ABS
C2007:13
Right Motor:Circuit Open
GO to Pinpoint Test D
ABS
C2007:1C
Right Motor:Circuit Voltage Out Of Range
GO to Pinpoint Test D
ABS
C2007:92
Right Motor:Performance Or Incorrect Operation
GO to Pinpoint Test D
ABS
C2008:13
Left Motor:Circuit Open
GO to Pinpoint Test D
ABS
C2008:1C
Left Motor:Circuit Voltage Out Of Range
GO to Pinpoint Test D
ABS
C2008:92
Left Motor:Performance Or Incorrect Operation
GO to Pinpoint Test D
ABS
U2002:00
Switch:No Sub Type Information
GO to Pinpoint Test J
ABS
U2002:47
Switch:Watchdog/Safety µC Failure
GO to Pinpoint Test B
Symptom Chart(s)
Symptom Chart: Parking Brake and Actuation
Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices...
