Capacities

Materials

Other information:
WARNING: If the tire pressure
monitor sensor becomes damaged it may
not function.
Note: You should only use tire sealants in
roadside emergencies as they may cause
damage to the tire pressure monitoring
system sensor.
Note: The tire pressure monitoring system
indicator light illuminates when the spare
tire is in use...
System Operation
System Diagram
Item
Description
1
HVAC control module
2
Rear air distribution door actuator
3
Rear temperature door actuator
4
Rear blower motor relay
5
Rear blower motor speed control
6
Rear blower motor
7
Rear air discharge temperature sensor
8
Rear temperature sensor - Second Row
9
Rear footwell air discharge temperature sensor
10
Rear temperature sensor - Third Row
11
IPC
12
GWM
13
FCIMB
14
RACM (Rear Touch screen)
15
APIM ( FDIM Touch Screen)
16
RHVAC control module (Rear Non touch screen)
Network Message Charts
Module Network Input Messages - APIM
Broadcast Message
Originating Module
Message Purpose
Climate control button status
HVAC control module
This message contains the HVAC climate control settings for the touch screen display...
