Lincoln Aviator 2020-2026 Service Manual: Description and Operation - Parking Aid - System Operation and Component Description

System Operation Parking Aid - Audible System Diagram - Without 360 Degree View Camera Item Description 1 PAM 2 LHR outer sensor 3 LHF outer sensor 4 LHF inner sensor 5 RHF inner sensor 6 RHR outer sensor 7 RHF outer sensor 8 RHR inner sensor 9 LHR inner sensor 10 Parking aid disable switch 11 PCM 12 ABS module 13 GWM 14 TRM 15 BCM 16 ACM 17 IPC 18 APIM 19 DSP 20 Rear door speakers 21 Front door speakers 22 with 14 or 28 speaker system System Diagram - With 360 Degree View Camera Item Description 1 PCM 2 IPMB 3 LHR outer sensor 4 ABS module 5 GWM 6 TRM 7 BCM 8 ACM 9 IPC 10 APIM 11 DSP 12 Rear door speakers 13 Front door speakers 14 LHF outer sensor 15 LHF inner sensor 16 RHF inner sensor 17 RHR outer sensor 18 RHF outer sensor 19 RHR inner sensor 20 LHR inner sensor 21 Right front active sensor 22 Left front active sensor 23 Right rear active sensor 24 Left rear active sensor 25 Parking aid disable switch 26 PAM 27 with 14 or 28 speaker system Network Message Chart   PAM Network Input Messages Broadcast Message Originating Module Message Purpose Gear position   PCM Enables or disables the front or rear parking aid depending on the gear lever position...

Lincoln Aviator 2020-2026 Service Manual: Diagnosis and Testing - Instrumentation, Message Center and Warning Chimes - Vehicles With: Head Up Display (HUD)

Diagnostic Trouble Code (DTC) Chart Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices. REFER to: Diagnostic Methods (100-00 General Information, Description and Operation).   Diagnostic Trouble Code Chart Module   DTC Description Action   HUD U0100:00 Lost Communication With ECM/PCM "A":No Sub Type Information   GO to Pinpoint Test J   HUD U0140:00 Lost Communication With Body Control Module:No Sub Type Information   GO to Pinpoint Test K   HUD U0164:00 Lost Communication With HVAC Control Module:No Sub Type Information   GO to Pinpoint Test M   HUD U0208:00 Lost Communication With "Seat Control Module A":No Sub Type Information   GO to Pinpoint Test N   HUD U0212:00 Lost Communication With Steering Column Control Module:No Sub Type Information   GO to Pinpoint Test O   HUD U0232:00 Lost Communication With Side Obstacle Detection Control Module "A":No Sub Type Information   GO to Pinpoint Test P   HUD U0233:00 Lost Communication With Side Obstacle Detection Control Module "B":No Sub Type Information   GO to Pinpoint Test P   HUD U0238:00 Lost Communication With Digital Audio Control Module "D":No Sub Type Information   GO to Pinpoint Test Q   HUD U023A:00 Lost Communication With Image Processing Module A:No Sub Type Information   GO to Pinpoint Test R   HUD U0401:00 Invalid Data Received from ECM/PCM A:No Sub Type Information   GO to Pinpoint Test J   HUD U0401:81 Invalid Data Received from ECM/PCM A:Invalid Serial Data Received   GO to Pinpoint Test J   HUD U0401:82 Invalid Data Received from ECM/PCM A:Alive/Sequence Counter Incorrect/Not Updated   GO to Pinpoint Test J   HUD U0405:56 Invalid Data Received From Cruise Control Module:Invalid/Incompatible Configuration   GO to Pinpoint Test S   HUD U0424:00 Invalid Data Received From HVAC Control Module:No Sub Type Information   GO to Pinpoint Test M   HUD U0424:81 Invalid Data Received From HVAC Control Module:Invalid Serial Data Received   GO to Pinpoint Test M   HUD U0424:82 Invalid Data Received From HVAC Control Module:Alive/Sequence Counter Incorrect/Not Updated   GO to Pinpoint Test M   HUD U0429:00 Invalid Data Received From Steering Column Control Module:No Sub Type Information   GO to Pinpoint Test O   HUD U0429:82 Invalid Data Received From Steering Column Control Module:Alive/Sequence Counter Incorrect/Not Updated   GO to Pinpoint Test O   HUD U0431:00 Invalid Data Received From Body Control Module "A":No Sub Type Information   GO to Pinpoint Test K   HUD U0509:82 Invalid Data Received From "Seat Control Module A":Alive/Sequence Counter Incorrect/Not Updated   GO to Pinpoint Test N   HUD U2100:00 Initial Configuration Not Complete:No Sub Type Information   GO to Pinpoint Test T   HUD U2300:55 Central Configuration:Not Configured   GO to Pinpoint Test S   HUD U3000:04 Control Module:System Internal Failures   GO to Pinpoint Test U   HUD U3000:41 Control Module:General Checksum Failure   GO to Pinpoint Test U   HUD U3000:42 Control Module:General Memory Failure   GO to Pinpoint Test U   HUD U3000:47 Control Module:Watchdog/Safety µC Failure   GO to Pinpoint Test U   HUD U3000:49 Control Module:Internal Electronic Failure   GO to Pinpoint Test U   HUD U3001:98 Control Module Improper Shutdown Performance:Component Or System Over Temperature   GO to Pinpoint Test V   HUD U3003:16 Battery Voltage:Circuit Voltage Below Threshold   GO to Pinpoint Test X   HUD U3003:17 Battery Voltage:Circuit Voltage Above Threshold   GO to Pinpoint Test Y   HUD U300A:64 Ignition Switch:Signal Plausibility Failure   GO to Pinpoint Test W Symptom Chart Symptom Chart: HUD Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices...
