Lincoln Aviator: Glass, Frames and Mechanisms / Removal and Installation - Rear Door Window Glass

Removal and Installation - Rear Door Window Control Switch

Special Tool(s) / General Equipment Interior Trim Remover Removal NOTE: LH (left-hand) side shown, RH (right-hand) side similar. Remove the rear door window control switch bezel assembly...

Removal and Installation - Rear Door Window Regulator and Motor

Special Tool(s) / General Equipment Punch Removal NOTE: Left hand (LH) shown, right hand (RH) similar. NOTE: For rear door window regulator motors that are non-functional it will be necessary to remove the rear door window regulator motor prior to removing the rear door window regulator...

Other information:

Lincoln Aviator 2020-2026 Service Manual: Diagnosis and Testing - Instrumentation, Message Center and Warning Chimes - Vehicles With: Head Up Display (HUD)

Diagnostic Trouble Code (DTC) Chart Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices. REFER to: Diagnostic Methods (100-00 General Information, Description and Operation).   Diagnostic Trouble Code Chart Module   DTC Description Action   HUD U0100:00 Lost Communication With ECM/PCM "A":No Sub Type Information   GO to Pinpoint Test J   HUD U0140:00 Lost Communication With Body Control Module:No Sub Type Information   GO to Pinpoint Test K   HUD U0164:00 Lost Communication With HVAC Control Module:No Sub Type Information   GO to Pinpoint Test M   HUD U0208:00 Lost Communication With "Seat Control Module A":No Sub Type Information   GO to Pinpoint Test N   HUD U0212:00 Lost Communication With Steering Column Control Module:No Sub Type Information   GO to Pinpoint Test O   HUD U0232:00 Lost Communication With Side Obstacle Detection Control Module "A":No Sub Type Information   GO to Pinpoint Test P   HUD U0233:00 Lost Communication With Side Obstacle Detection Control Module "B":No Sub Type Information   GO to Pinpoint Test P   HUD U0238:00 Lost Communication With Digital Audio Control Module "D":No Sub Type Information   GO to Pinpoint Test Q   HUD U023A:00 Lost Communication With Image Processing Module A:No Sub Type Information   GO to Pinpoint Test R   HUD U0401:00 Invalid Data Received from ECM/PCM A:No Sub Type Information   GO to Pinpoint Test J   HUD U0401:81 Invalid Data Received from ECM/PCM A:Invalid Serial Data Received   GO to Pinpoint Test J   HUD U0401:82 Invalid Data Received from ECM/PCM A:Alive/Sequence Counter Incorrect/Not Updated   GO to Pinpoint Test J   HUD U0405:56 Invalid Data Received From Cruise Control Module:Invalid/Incompatible Configuration   GO to Pinpoint Test S   HUD U0424:00 Invalid Data Received From HVAC Control Module:No Sub Type Information   GO to Pinpoint Test M   HUD U0424:81 Invalid Data Received From HVAC Control Module:Invalid Serial Data Received   GO to Pinpoint Test M   HUD U0424:82 Invalid Data Received From HVAC Control Module:Alive/Sequence Counter Incorrect/Not Updated   GO to Pinpoint Test M   HUD U0429:00 Invalid Data Received From Steering Column Control Module:No Sub Type Information   GO to Pinpoint Test O   HUD U0429:82 Invalid Data Received From Steering Column Control Module:Alive/Sequence Counter Incorrect/Not Updated   GO to Pinpoint Test O   HUD U0431:00 Invalid Data Received From Body Control Module "A":No Sub Type Information   GO to Pinpoint Test K   HUD U0509:82 Invalid Data Received From "Seat Control Module A":Alive/Sequence Counter Incorrect/Not Updated   GO to Pinpoint Test N   HUD U2100:00 Initial Configuration Not Complete:No Sub Type Information   GO to Pinpoint Test T   HUD U2300:55 Central Configuration:Not Configured   GO to Pinpoint Test S   HUD U3000:04 Control Module:System Internal Failures   GO to Pinpoint Test U   HUD U3000:41 Control Module:General Checksum Failure   GO to Pinpoint Test U   HUD U3000:42 Control Module:General Memory Failure   GO to Pinpoint Test U   HUD U3000:47 Control Module:Watchdog/Safety µC Failure   GO to Pinpoint Test U   HUD U3000:49 Control Module:Internal Electronic Failure   GO to Pinpoint Test U   HUD U3001:98 Control Module Improper Shutdown Performance:Component Or System Over Temperature   GO to Pinpoint Test V   HUD U3003:16 Battery Voltage:Circuit Voltage Below Threshold   GO to Pinpoint Test X   HUD U3003:17 Battery Voltage:Circuit Voltage Above Threshold   GO to Pinpoint Test Y   HUD U300A:64 Ignition Switch:Signal Plausibility Failure   GO to Pinpoint Test W Symptom Chart Symptom Chart: HUD Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices...

Lincoln Aviator 2020-2026 Service Manual: Installation - Engine Block Skirt Stiffener

Special Tool(s) / General Equipment 205-153 (T80T-4000-W) Handle 303-1246Engine Spreader BarTKIT-2006UF-FLMTKIT-2006UF-ROW 303-1247VCT Spark Plug Tube Seal Remover and InstallerTKIT-2006UF-FLMTKIT-2006UF-ROW 303-1250Seal Installer, Rear MainTKIT-2006UFFLM 303-1531Installer, Front Crank Seal and Damper 303-1634Lift Eyes (2)TKIT-2014D-ROW3TKIT-2014D-FL_ROW 303-335 (T88T-6701-A) Installer, Front Cover Oil SealTKIT-1988-FLMTKIT-1988-F Floor Crane Mounting Stand Plastic Scraper Flat-Bladed Screwdriver Vise Vise Jaw Protectors Materials Name Specification Motorcraft® High Performance Engine RTV SiliconeTA-357 WSE-M4G323-A6  Motorcraft® Silicone Gasket RemoverZC-30-A -  Motorcraft® Metal Surface Prep WipesZC-31-B -  Motorcraft® Metal Brake Parts CleanerPM-4-A, PM-4-B -  NOTICE: During engine repair procedures, cleanliness is extremely important...
